Drawings of 150330 Mampong Waterstation

this is the link to drawings of project 150330 Mampong Waterstation

https://drive.google.com/open?id=0B29Q6crFvCxKdzlnODltM3JGQjA

Fencing Estimate for 150929 Nkwantakese Project

I started gathering information, prices and company contacts for the fencing project on Monday 5 October, 2015.
I received responds from one company and prepared it for submission on Tuesday 6th October, 2015.

Trip to New Project site at Nkwantakese

Infra-tec-gh engineers has gotten two new water project at Nkwantakese.
The projects are :

150928 water project, manager: David.,

150929 water project, manager: Sulley

Electrical Building drawings

4. Sept 2015 No info

About what is going i did not see any info !

The drilling position can be as well at the 6 plot place ... check for the best place in all 10 plots ..

... and where are the prises and phone Nr from the workers in Mampong ?

( el, plumb, plast,..)

Trip to Mampong Nord, Waterstation project Land Site

On the 31st of August 2015 Infratec-GH Team visited the land site at Mampong  for their first project.
The member of the team which join the trip was Mr. Panford, Mr. Sulley, Mr. David.
We set-off for Mampong at 9:10 am and returned at 4:30 pm.
Gloria was contacted at Mampong, and took us to the land site and around town.
The whole land was identified and the specific part for the for the borehole project was also identified including the marked stone which shows the boundaries of the land.
Pictures of the land and marked stones is posted below.

https://drive.google.com/open?id=0B29Q6crFvCxKflNCamtGRWVfMEdfaHV0OTlyLVZET3I0YjNkMWNwZUxqYTdWMFJXZnNR

Site Plan

This diagram is designed by Mr.Sulley
Time used : 2hour

Recent Activity of Infra-Tec GH team

The Infratec GH team first project, mampong water station. Mr panford and Mr Sullley has been selected for the project management.

Task list of the project has been created in yesterdays meeting

Other activity
working on unicenta inventory data entry.
Problem encountered transfering of database
(solved) now we can share data between one another.

Sample of Infr@tec.gh Logo

Congratulations

A grate day for you ... and be happy in all your ways .. pp

My Congregational ceremony on the 18th of july

This day was the day I completed Kumasi Polytechnic and I was awarded with a Higher National Diploma (HND) in Electrical / Electronic Engineering certificate. I was also awarded the best Electrical / Electronic Engineering student in our department.

schematic diagram

Schematic diagram

Inconsistencies of blog postings

Recent breaks of my blog postings was as a result of my laptop screen damage.
Now it is fixed and good to go, so i will be updating my blog soon.


Also i have been having problems with the installation of the unicenta, it keeps on asking about java runtime. Now we have schedule a meeting between us, some where this week to discuss about unicenta and further discuss about Eplan but this week we are having mid-semester examination.

29.Apr BLOG-LINKs

GSE-p1a is Stephen http://gsep1.blogspot.ch/  ...
GSE-p1b is David http://gsep4david.blogspot.ch/ ...
GSE-p1c is Mustapha http://sulleymustapha.blogspot.com/ (this BLOG) ...
GSE-p1d is Emmanuel http://gsep2.blogspot.com

SCHEMATIC DIAGRAM PAGE 12,13,14,15

schematic diagram page 11

problem : no
Questions: no

Schematic diagram

Schematic Diagram

SCHEMATIC DIAGRAM 3

Please some of the component are not easily identified from the diagram given since our Eplan software is newer version. so is it ok to use similar components.
we have been communicating with each other on the eplan software so we are progressing.

COMMENTS

thanks for your comment, we will be looking forward to meet you.

23.March 2015 ... there are the first diagramms

i see there is some progress .. am happy ...

woud bee nice to see more days working on it ...

delete the empty posts in your blog

look at p1a blog .. am comming after easter to see you as well .. pp

Eplan Schematic Drawings

11.March 2015 .. now i can add some posts here ..

Hi .. you startet well ..

Now you shoud try to make your El. Diagramm from your home with ePLAN and put it here ...

(like Stephen did)

Then go and do the list with the sample download ...
like this and the LINK:

9.Mrz 2015 El.Sample

El-Sample for EPLAN

a) Try to download 2 MB PDF ---
b) Try to understand the scamatic and el.wiering
c) Try to make this in your ePLAN

pp

Excel Logic Equations Test

Excel Logic test

   Ashanti Home touch Meeting
